Q15K-500
Huanhong
Availability: | |
---|---|
Quantity: | |
Q15 series scrap metal hydraulic gantry shearing machine is a large hydraulic shearing equipment designed for metal recycling, metallurgy, scrap car dismantling and other industries. It is mainly used for cold shearing of various scrap metal plates or structural parts such as steel plates, copper plates, nickel plates, steel sections, steel billets, steel pipes, etc., replacing traditional flame cutting. It has the advantages of high efficiency, energy saving, safety and low noise.
1. Hydraulic Drive: Utilizes integrated electro-hydraulic control with single/continuous action switching, ensuring smooth operation, low noise, and flexible operation.
2. Gantry Structure: The entire machine features a welded steel box structure, offering strong rigidity and high stability. The shear cylinder utilizes a ball joint connection for extended service life.
3. High Shear Force: Optional shear forces range from 120 to 400 tons, with maximum shear thicknesses of 30 to 35 mm and blade lengths ranging from 800 to 1600 mm.
4. High Energy Efficiency: Achieves 6 to 12 shears per minute, with some high-end models reaching up to 20 shears per minute.
5. High Safety: Equipped with overload protection, the machine can be started and stopped from any position, and is easily operated using buttons or a foot pedal.
Technical specification of Q15 series shearing machine | |
Model | Q15-500 |
Nominal pressure | 5000 kn |
Blade length | 1200 mm |
Material Bin size | 3500*1150*200 mm |
Cutting times | 3~5 times/min |
Power Specifications | 380V/3P 50Hz |
Total equipment power | 90 KW |
Hydraulic system working pressure | 22 MPa |
The above parameters are for reference only. The shears can be customized.
The Q15 hydraulic gantry shearing machine is a cold shearing tool suitable for all kinds of metals: whether you send thin steel plates, thick copper plates, nickel alloys, stainless steel, angle steel, channel steel, round steel, steel pipes, or steel billets, it can shear them into standard blocks that meet the requirements of smelting or transportation at one time. For this reason, it has become the core front-end equipment of scrap metal recycling and processing centers, steel plant affiliated enterprises, scrap car dismantling sites, smelting and casting workshops, and various non-ferrous metal processing enterprises - turning messy scrap steel into regular materials that can be directly recycled, pushing recycling efficiency and profit margins to new heights.
